The Signal Hound TG124A is a compact, USB-powered RF signal generator that covers a frequency range of 9 kHz to 2.4 GHz. Designed for general-purpose RF testing, component characterization, IoT device validation, and educational applications, its functionality can be significantly enhanced when paired with complementary products. These compatible products range from core control software and test instruments to essential accessories and target devices under test (DUTs). Below is a detailed breakdown of the key products to use with the TG124A for optimal performance and expanded application capabilities.

1. Core Control Software: Signal Hound Spike® RF Analysis Software

The TG124A relies on Signal Hound’s proprietary Spike RF analysis software as its primary control and operation platform—this is essential for unlocking the generator’s full capabilities. Without Spike software, the TG124A cannot be configured or controlled, as it lacks standalone physical controls.

Spike software enables users to:
    - Intuitively set key signal parameters (frequency, output power, attenuation, and modulation type).
    - Access and customize modulation formats, including analog (AM, FM, PM, Pulse) and digital (QPSK, 16QAM) modulations, as well as import and play back custom IQ waveforms.
    - Monitor signal output in real time when paired with a spectrum analyzer, and generate automated test scripts via Signal Hound’s Software Development Kit (SDK), which supports Python, C/C++, and .NET programming languages.
    - The software is compatible with Windows 10/11 (64-bit) and Linux (Ubuntu 20.04 LTS or later), and can be downloaded for free from the Signal Hound official website.

2. Complementary Test Instruments: Signal Hound Spectrum Analyzers

For closed-loop RF testing (where signal generation is paired with signal analysis), the TG124A works seamlessly with Signal Hound’s spectrum analyzers. This combination creates a unified, cost-effective test system that is ideal for verifying signal quality and validating DUT performance.

Recommended compatible spectrum analyzers include:
    - Signal Hound SA124B: A portable spectrum analyzer covering 9 kHz to 12.4 GHz. When paired with the TG124A, it can verify the TG124A’s output signal quality (e.g., phase noise, harmonic distortion) and analyze the response of DUTs (such as filters or amplifiers) to the signals generated by the TG124A.
    - Signal Hound SM435C: A higher-performance spectrum analyzer with a frequency range of 9 kHz to 43.5 GHz. Suitable for more advanced testing scenarios, such as validating the performance of 2.4 GHz Wi-Fi or Bluetooth modules (generated by the TG124A) with high-precision signal analysis.


The integration of the TG124A and Signal Hound spectrum analyzers via Spike software allows for unified control of both instruments from a single interface, eliminating the need to switch between multiple software platforms and streamlining the testing workflow.

3. Essential RF Test Accessories

A range of RF accessories is required to ensure reliable signal transmission, protect equipment, and adapt to different testing environments. These accessories are critical for the practical use of the TG124A:

• SMA RF Cables: High-quality SMA male-to-female coaxial cables (e.g., RG-316 or RG-174) are needed to connect the TG124A’s RF output port to DUTs, spectrum analyzers, or other test equipment. These cables ensure low signal loss and stable transmission, especially at higher frequencies (up to 2.4 GHz).


• RF Attenuators: Fixed or variable attenuators (typically 0–60 dB with 0.1 dB step resolution) are essential for protecting sensitive DUTs (such as low-noise amplifiers or IoT sensor receivers) from excessive signal power. They also help adjust the signal level to match the dynamic range requirements of the test scenario.


• Power Supplies: The TG124A can be powered via a USB 3.0/2.0 Type-C cable connected to a computer. For field testing or scenarios where a computer is unavailable, an optional 5V DC power adapter (with a minimum output current of 2A) provides a stable power source for extended operation.


• RF Antennas: For wireless testing scenarios (e.g., validating the range of 2.4 GHz IoT devices), SMA-compatible omnidirectional or directional antennas can be connected to the TG124A’s RF output port. These antennas convert the generator’s guided RF signals into radiated signals, enabling wireless signal propagation testing.


• 10 MHz Reference Source (Optional): For applications requiring higher frequency accuracy (e.g., precise component characterization), an external 10 MHz reference source can be connected to the TG124A (via an optional adapter) to synchronize the generator’s internal oscillator, reducing frequency drift.

4. Devices Under Test (DUTs)

The TG124A is designed to generate test signals for a wide range of low-to-mid RF band devices. The specific DUTs paired with the TG124A depend on the application scenario, but common examples include:

• RF Components: Filters (e.g., 2.4 GHz band-pass filters), amplifiers, mixers, oscillators, and attenuators. The TG124A generates test signals to characterize key parameters such as insertion loss, gain, frequency response, and linearity.


• Wireless/IoT Modules: 2.4 GHz Bluetooth (Classic/BLE), Zigbee, Wi-Fi (802.11b/g/n), and LoRa modules. The TG124A simulates wireless signals to test the receiver sensitivity, demodulation accuracy, and anti-interference capability of these modules.

• Consumer Electronics: AM/FM radio receivers, TV tuners, wireless remote controls, and portable wireless speakers. The TG124A provides standard test signals to verify the performance and compliance of these devices.


• Educational Test Benches: For academic or training purposes, the TG124A is paired with basic RF test components (e.g., dipoles, transmission lines) to demonstrate signal generation, modulation, and propagation principles.

Summary of Key Recommendations

To maximize the value of the Signal Hound TG124A, the following combinations are most practical for different use cases:
    - Basic Operation: TG124A + Spike software + USB cable + SMA RF cable.
    - Closed-Loop Testing: TG124A + Spike software + Signal Hound SA124B/SM435C + attenuators + RF cables.
    - Field Wireless Testing: TG124A + Spike software + 5V DC power adapter + SMA antenna + RF cables.
    - Precision Component Testing: TG124A + Spike software + external 10 MHz reference source + spectrum analyzer + high-precision attenuators.


By selecting the appropriate complementary products, the TG124A can adapt to diverse testing needs—from basic educational experiments to professional IoT device validation and RF component characterization—delivering reliable and cost-effective performance across scenarios.
