rohde schwarz FSV3030 Signal and spectrum analyzer，10 Hz to 30 GHz
rohde schwarz FSV3030 Signal and spectrum analyzer，10 Hz to 30 GHz
Key facts
Frequency range from 10 Hz to 30 GHz
Analysis bandwidth up to 200 MHz
SSB phase noise at 10 kHz offset (1 GHz): –114 dBc/Hz
GUI with multi-touch, SCPI recorder and event based actions
Options for analog and digital signal analysis, including 5G NR
Key Features
▶ Supports the latest digital communication standards including 5G NR
▶ Choose from two different versions based on required performance
▶ Maximum frequency of 54 GHz
▶ Phase noise (1 GHz, 10 kHz offset): R&S®FSVA3000: -127 dBc/Hz, R&S®FSV3000: -114 dBc/Hz
▶ IQ analysis bandwidth: R&S®FSVA3000: maximum 1 GHz bandwidth; R&S®FSV3000: maximum 200 MHz bandwidth
▶ Innovative GUI for simple implementation of complex measurements
Fast and simple setup for fast access to measurement results
The R&S®FSV3000 signal and spectrum analyzer performs measurements at the push of a button, uses event based actions for capture and makes script programming simple with a SCPI recorder – for quick setups of complex measurements. Fast measurement speeds for high throughput in production applications are another major advantage.
Available models
R&S®FSV3004 Order number 1330.5000.04 10 Hz - 4 GHz <–114 dBc (1 Hz)(f = 1 GHz, 10 kHz offset, option B710) <–162dBm/Hz 200 MHz
R&S®FSV3007 Order number 1330.5000.07 10 Hz - 7.5 GHz <–114 dBc (1 Hz)(f = 1 GHz, 10 kHz offset, option B710) <–162 dBm/Hz 200 MHz
R&S®FSV3013 Order number 1330.5000.13 10 Hz - 13.6 GHz <–114 dBc (1 Hz)(f = 1 GHz, 10 kHz offset, option B710)<–162 dBm/Hz 200 MHz
R&S®FSV3030 Order number 1330.5000.30 10 Hz - 30 GHz <–114 dBc (1 Hz)(f = 1 GHz, 10 kHz offset, option B710)<–162 dBm/Hz 200 MHz
R&S®FSV3044 Order number 1330.5000.43 10 Hz - 44 GHz <–114 dBc (1 Hz)(f = 1 GHz, 10 kHz offset , option B710)<–162 dBm/Hz 200 MHz
R&S®FSV3050 Order number 1330.5000.50 10 Hz - 50 GHz <–114 dBc (1 Hz)(f = 1 GHz, 10 kHz offset, option B710)<–162 dBm/Hz 200 MHz
